Novel Optical Microscopies to Unravel Brain Function

CHIAO HUANG, KUO-JEN HSU, HAN-YUAN LIN, SHI-WEI CHU

DEPARTMENT OF PHYSICS, NATIONAL TAIWAN UNIVERSITY, TAIWAN



ABSTRACT


Brain function stems from emergent properties of interconnected neuron networks, which requires in vivo volumetric imaging with high spatial/temporal resolution. Here, we introduce our recent technical developments for Drosophila brain imaging.


INTRODUCTION


The brain is one of the most important organs in our body, but it is functionally the least understood one. It is composed of millions of neurons, whose interconnection, i.e. connectome, determines its function. Although the interaction of neurons in vitro has been well studied in the past century, no existing tool can capture whole-brain emergent properties at single neuron or even synapse resolution. To understand functional connectome, an imaging system that can cover a whole brain in vivo with spatial resolution of micrometers (neuron) to nanometers (synapse) as well as temporal resolution in sub-seconds (calcium) to milliseconds (action potential) is highly desirable. In this focus article, we introduce our recent efforts to improve optical microscopy in terms of speed, depth, and spatial resolution, toward the goal of understanding the brain of Drosophila, which offers a small brain with sophisticated functions and genetic control capabilities.


High speed volumetric imaging with millisecond temporal resolution


Neurons are distributed in three dimensions in the brain, and their firing dynamic is in the millisecond scale. To observe their functional connections in vivo, we developed a high-speed volumetric imaging system by combining a conventional two-photon microscope with a tunable acoustic gradient-index (TAG) lens [1]. The TAG lens is based on acoustic resonance, which in turn creates periodic gradient index modulation up to MHz speed, thus enabling high-speed axial scanning when combined with a microscope objective [2, 3]. Fig. 1 (a) shows that we can convert a plane scan in the xy plane into volumetric imaging with sub-second imaging speed. Fig. 1(b) is a line scan in the xy plane converted into a "ribbon" scan in xyz volume, with temporal resolution approaching the millisecond scale.


Volumetric all-optical physiology


To further unravel the in vivo functional connections, it is necessary to incorporate high-precision stimulation capabilities into a volumetric imaging system, i.e., a volumetric all-optical physiology that uses photons to manipulate and report neuron activities [4]. Fig. 2 presents our results in Drosophila's visual pathway, where we were able to stimulate upstream neurons and record the downstream neuronal responses in 3D, thus resolving the neural coding scheme of vision.



Whole-brain super-resolution imaging


In the above results, optical microscopy provides sub-μm spatial resolution, limited by diffraction. The neural fibers and synapses inside a Drosophila brain can be much smaller, so super-resolution techniques that break the diffraction barrier are required. However, conventional super-resolution modalities are mostly not applicable at the tissue level due to their susceptibility for aberration and scattering. We recently developed COOL (Confocal lOcalization deep-imaging with Optical cLearing) [5], which combines advanced techniques using blinking fluorescence proteins, confocal microscopy, optical clearing, and localization microscopy to achieve 20-nm spatial resolution across a whole brain of Drosophila. Fig. 3(a) shows resolving densely entangled dendritic fibers in an intact Drosophila brain with unprecedented depth/resolution performance in 3D (inset: in the same structure mapped by confocal microscopy, no fibrils can be observed).


Whole-brain imaging in a living Drosophila brain


It is well known that two-photon microscopy provides ~1-mm penetration depth in a mouse brain, but when imaging the Drosophila brain, it is mysterious that the imaging depth cannot exceed 0.1 mm! We recently unraveled the underlying mechanism as a strong optical aberration from the trachea, which delivers oxygen in insects. As shown in Fig. 3(b), we used long-wavelength three-photon microscopy to reduce the aberration and therefore achieved whole-brain observation with single neuron resolution in a living Drosophila brain [6].



CONCLUSION


For developing a bio-imaging system, the most important factors are contrast, resolution, speed, and depth. By combining interesting physics concepts (such as acoustic resonance for volumetric imaging, high-precision focusing for precise stimulation, localization calculations for super-resolution microscopy, and three-photon excitation for deep-tissue imaging) with innovative biological concepts, (including calcium/voltage sensitive fluorescent protein labeling, optogenetic stimulation, and optical clearing), we push the limits of optical microscopy in all four areas. These novel techniques will benefit not only brain science research but also studies in other bio-tissues.


Acknowledgements: The above work was supported by the Outstanding Young Scholarship Project of Ministry of Science and Technology (MOST), Taiwan, under grant MOST-105-2628-M-002-010-MY4, and MOST-108-2321-B-002-058-MY2. The work was also supported by the Higher Education Sprout Project funded by the Ministry of Science and Technology, and the Ministry of Education of Taiwan.


References


[1] K.-J. Hsu, et al., Opt. Lett. 44, 3190 (2019). Editor's pick [2] L. Kong, et al., Nat. Methods. 12, 759 (2015). [3] K.-J. Hsu, et al., Opt. Express. 25, 16783 (2017). [4] C. Huang, et al., iScience. 22, 133 (2019). [5] H.-Y. Lin, et al., iScience. 14, 164 (2019). [6] K.-J. Hsu., et al., Biomed. Opt. Exp. 10, 1627 (2019).



Chiao Huang is a PhD student at the University of Arizona. She received her master's degree from the Institute of Applied Physics, National Taiwan University (NTU) in 2018. Her master's thesis focused on building an all-optical physiology platform for observing neuron connection in the living Drosophila brain.








Han-Yuan Lin received his master's degree from Department of Physics, National Taiwan University (NTU) in 2019. His master's thesis concentrated on deep-tissue super-resolution microscopy in an intact Drosophila brain.










Kuo-Jen Hsu is a researcher at ASML in the Netherlands, and he is working on the development of lithography machines for the semiconductor industry. He received his PhD from the Department of Physics, National Taiwan University (NTU) in 2018. His dissertation addressed the development of optical imaging techniques for brain functional studies.







Shi-Wei Chu is a professor in the Department of Physics, National Taiwan University (NTU). He serves as the vice director for both the Center for Teaching and Learning Development and the Digital Learning Center, at NTU. He is also the associate director on innovative teaching at NTU's D.school. His research focuses on improving optical microscopy for interdisciplinary research applications. He has received the Outstanding Young Scholar Research Project Award from the Ministry of Science and Technology, Taiwan; the Young Scholars' Creativity Award from the Foundation for the Advancement of Outstanding Scholarship; the Excellent Mentor Award of NTU; and the Outstanding Teaching Award of NTU. As a faculty member, he is particularly proud of his supervised students, who have received more than 50 international and domestic research awards.
